Hover to zoomAVMATRIX UC2018 HDMI/SDI to USB-C Capture
Choose your dates · Prices + VAT
What's in the case
Content list
- 1×AVMATRIX UC2018 capture device
- 1×USB-A to USB-C cable
The gear
About this gear
The AVMATRIX UC2018 is a small USB capture device with one 3G-SDI input and one HDMI 1.4a input. It detects which input is active and captures that source at up to 1080p60 as uncompressed YUY2 video, at up to 200MB/s over USB 3.1 Gen 1 Type-C. Audio comes from the embedded SDI or HDMI signal or from a 3.5 mm line input. It is bus-powered (3.5W) and uses the standard UVC and UAC classes, so Windows, macOS and Linux need no drivers.
On a production it turns an SDI feed, such as a switcher aux or a camera output, into a webcam-style source on a laptop. That makes it a quick way to get programme video into OBS, a Zoom or Teams call with remote guests, or a backup recording machine.
Highlights
- 013G-SDI and HDMI 1.4a inputs with automatic input detection
- 02Uncompressed YUY2 capture up to 1080p60, up to 200MB/s over USB 3.1 Gen 1
- 03UVC/UAC class device: driver-free on Windows, macOS and Linux
- 04Bus-powered over USB-C (3.5W), no external supply
- 05Audio from SDI/HDMI embedded channels or a 3.5 mm line input
FAQ
Questions about this gear
No. It has both inputs but captures one source at a time, picking the active input automatically. Two feeds need two units.
No. The maximum capture format is 1080p60, so sources must be HD or SD.
Neither. It is a UVC/UAC device powered by the USB connection; use a USB 3 port for full-rate uncompressed capture.
