What's in the case
Content list
- 1×DJI SDR Transmission transmitter (TX)
- 1×DJI SDR Transmission receiver (RX)
- 3×NP-F970 battery
- 1×NP-F battery charger
- 1×USB-A to USB-C cable
The gear
About this gear
DJI SDR Transmission is a 1080p60 wireless video link built on software-defined radio rather than Wi-Fi, using the 2.4 GHz and 5.8 GHz bands plus 5.47-5.725 GHz DFS channels. DJI quotes up to 2 km under CE rules (3 km FCC) in Control mode with Broadcast mode off, 20 Mbps H.264 and 35 ms latency at 1080p60, excluding camera and display. The transmitter takes SDI or HDMI; the receiver outputs SDI, HDMI and USB-C.
Each unit weighs about 145 g and runs from an NP-F battery or USB-C power, and on an RS 4, RS 4 Pro or RS 3 Pro gimbal the transmitter can be powered by the gimbal. Broadcast mode sends one feed to any number of receivers, which helps when a director, a client monitor and the switcher all need the same camera. A phone can also connect straight to the transmitter over Wi-Fi.
Highlights
- 011080p60 at 20 Mbps H.264, 35 ms latency excluding camera and display
- 02Up to 2 km (CE) / 3 km (FCC) in Control mode with Broadcast mode off
- 03Broadcast mode sends one transmitter to an unlimited number of receivers
- 04TX: SDI and HDMI in; RX: SDI, HDMI and USB-C out for phone or tablet monitoring
- 05Runs on NP-F batteries or USB-C (PD 9V/2A or 6.8-17.2V DC); about 145 g per unit
FAQ
Questions about this gear
One transmitter (TX) and one receiver (RX) working as a pair. More receivers can join the same transmitter in Broadcast mode.
Each unit takes an NP-F battery, or USB-C power from a PD supply (9V/2A) or a 6.8-17.2V DC source. Batteries are not part of this item.
Yes. With an RS 4, RS 4 Pro or RS 3 Pro the transmitter can be powered through the gimbal, and DJI supports Ronin remote control over the link.
Yes: connect a phone or tablet to the receiver with DJI's RX-to-phone cable, or straight to the transmitter over Wi-Fi (DJI quotes 200 m and 110 ms in Wi-Fi mode).
